Nanocomposite porous materials on the basis of titania and carbon for technologies of the use and accumulation of hydrogen

Proton conductivity as a function of temperature for Nafion(1) membrane and composite Nafion/ MeO membrane(2)

SEM image of the composite Nafion/MeO membrane

Brief description

New approach for design and modification of metal oxide porous nanosize particles able to polarization plenties of water molecules and method of doping of the Nafion membrane for giving of new properties toward development of performance and compactness high temperature fuel cell.

Expected results

The project is targeted on the development of the design and modification of the metal(Si, Ti) oxide nanocomposites various morphology able to polarization plenties of water molecules wherein swelling Nafion structure with the aim to provide the water management and their reliable operation at temperature > 100°C and to strengthen the mechanical stability the membrane.

Advantages

Fulfillment of the project can leads to improvement of performance and water management of polymer electrolyte composite membrane fuel cell at temperature >100°C, improve, on higher level of existed, increase of mechanical stability of the Nafion membrane. The results of project can be also used under development of of more compact fuel cells based on polymer membrane.

Competitors

Energy Systems Analysis Unit, Energy Department, CIEMAT Madrid, Spain.

Project development

The methods of synthesis of metal oxide nanoparticles with various morphology and approach for their modification are developed. The samples was characterized by XRD, FTIR, UV-VIS, XPS, TPD MS, TEM, SEM, AFM. The possibility of elaboration the nanocomposite samples with increased water retention was shown. Perspective proton conductivity of tested samples at 20-250°C and various humidity was established and verified. The methods of preparation of composite membrane are established. Test experiment for estimation of performance the composite membrane under preparation.

Intellectual propertyn

Patent on useful model under preparation

Contact information

Executor: L. Pisarzhevsky Institute of Physical Chemistry National Academy of Sciences of Ukraine

Project №30 “Nanocomposite porous materials on the basis of titania and carbon for technologies of the use and accumulation of hydrogen”

Contact person:

Тельбіз Герман Михайлович

Tel. +38(044)-525-5834

Е-mail: gtelbiz@yahoo.com
